STEEL DETAILING & DRAUGHTING FOR UK STEEL FABRICATION COMPANIES

We are a UK based company with many years of experience producing steel fabrication drawings for the UK steel industry. We provide a 3D modeling and steel detailing service using the latest CAD (Computer Aided Design) software for structural, architectural and miscellaneous steelwork. From large projects with hundreds of tonnes of steel and thousands of fabrication drawings to a fancy steel and glass handrail, we are equally capable. So, whether you are a company with its own steel detailing office or a one man operation, we can provide you with clear, error free steel fabrication drawings and NC files for your next project.

STEEL DETAILING AND BIM FOR UK BASED ENGINEERS AND ARCHITECTS

Why not let us take your conceptual drawings or sketches and turn them into a 3D models which can be used in all major CAD or BIM (Building Information Modelling) packages. We can use the model to produce clear steelwork general arrangement drawings showing plan views, elevations, sections and 3D views, all using your title blocks. The 3D CAD model can be easily shared with free viewing software so that your clients or contractors will immediately understand the structure. Many reports can also be generated giving you all the information you will need for a bill of quantities.
